This is a quick render of the exterior of the SketchUp model before i added wall thickness. However I still need to use the model with the thickened walls as when you paint the exterior of this model the interior turns white as well.
Thursday, April 29, 2010
Deep Exploration with SketchUp Development
This screen shows how i have thickened the walls on part of the model. The next step will be to continue it around and possibly cut out the repeated shape again through this layer.
Deep Exploration Import
After importing my model into deep exploration the materials from the inside are also showing on the outside. I think I will need to go back to SketchUp and make the walls thicker.
Wednesday, April 28, 2010
Tuesday, April 27, 2010
9 Sketches
Sketch 9
Change the shape of the model so that we can move through it. This isn't actualy possible when everything comes to a point. You would have to move through each thing seperately.
Sketch 8
Trying to made the shape a bit more interesting. Adding bits to the exterior of the shape.
Sketch 7
Just adding in more of the same model for repetition.
Sketch 6
Using design principal Rhythm. So it starts 4 high and then 3 etc.
Sketch 5
Using repetion which is the design principal from project 1 to create windows out of the same shape for light to go into the interior of the model.
Sketch 4
Thinking about moving parts. Possiblity to use as a lift to another level.
Sketch 3
Main center piece going right through with gaps between each layer of the diamond shapes.
Sketch 2
Having the diamond pieces on different levels, forming a staircase shape.
Sketch 1
Layering up and thinking about having the layers rotating around.
